Lugar de origem: | Província de Shandong, China |
---|---|
Marca: | SH |
Certificação: | ISO9001,CE |
Número do modelo: | Shjm350, shjm650, shjm800 |
Quantidade de ordem mínima: | 1 conjunto |
Preço: | US $7,500-13,950 / Set |
Detalhes da embalagem: | carga da embalagem ou do recipiente do quadro do ferro |
Tempo de entrega: | dentro de 15 dias |
Termos de pagamento: | T/T, Western Union |
Habilidade da fonte: | 1000 conjuntos/ano |
Nome: | a precisão resaw a serra de fita | Doença: | Novo |
---|---|---|---|
Tipo: | a faixa viu | Principal principal: | 15 kW, 18,5 kW, 22 kW |
Motor de alimentação: | 1,1kW, 1,5kW | Diâmetro da roda da serra: | 700 mm |
Largura máxima da serra: | 800mm | Máx. Altura de processamento: | 220mm |
Velocidade de alimentação: | Inversor, velocidade ajustável | Garantia:: | 1 ano |
Serviço pós-venda prestado: | Apoio em linha, suporte laboral video, comissão e treinando | ||
Destacar: | heavy duty horizontal resaw bandsaw,precision bandsaw machine with inverter,industrial wood saving bandsaw machine |
Beyond basic cutting, a precision resaw is an investment in productivity. Its core benefit lies in transforming challenging tasks—like salvaging expensive slabs or producing delicate veneers—into streamlined, repeatable processes. This is the definitive solution for professionals who require dependable performance day in and day out.
High-Output Efficiency with Power Feeding
Benefit: Dramatically increase production rates and achieve a perfect surface finish by automating the feed process. A power feeder provides a consistent, steady feed rate, which is crucial for both operator safety and optimal precision resawing.
Features Behind the Benefit: Driven by a high-torque motor and often paired with a carbide-tipped blade, the saw maintains consistent speed and power through the thickest materials.
Maximize Material Value and Versatility
Benefit: Recover the highest possible value from expensive lumber by efficiently resawing slabs and cants into thinner, usable boards. The wide resaw capacity opens up opportunities for diverse projects.
Typical Applications: Ideal for producing lumber, custom veneers, wood siding, and salvaging valuable material from live-edge slabs.
Horizontal Resaw Band Saw Mills | |||
Model | SH350 | SH650 | SH800 |
Saw Wheel Diameter | 710 mm | 710 mm | 710 mm |
Maximum Cutting Width | 350 mm | 650 mm | 800 mm |
Maximum working Wood Height | 200 mm | 220 mm | 220 mm |
Max Sawing Height
|
100 mm | 110 mm | 110 mm |
Min Sawing Thickness
|
2 mm | 2mm | 2mm |
Feeding speed | Variable Frequency Adjusted Speed | ||
Main Electric Motor Power | 15 KW | 18.5 KW | 18.5KW |
Up/down motor | 0.37kw | 0.37kw | 0.37kw |
Feeding motor | 1.1kw | 1.1kw | 1.5kw |
Machine Weight | 1000 KG | 1200 KG | 1400 KG |
Precision Slice Horizontal Band Sawmill
Model
|
SHJM-400
|
SHJM-650
|
SHJM-800
|
Saw Wheel Diameter
|
600MM
|
600MM
|
700MM
|
Max Sawing Wood Width
|
400MM
|
650MM
|
800MM
|
Max Sawing Height
|
110MM
|
||
Min Sawing Thickness
|
2MM
|
||
Feeding Speed
|
0.1-30 Meters/Minute
|
||
Motor Power
|
15KW
|
18.5KW
|
22KW
|
Feeding Motor
|
0.75KW |
0.75KW
|
1.5KW
|
We stand behind the durability of our precision resaw bandsaws. Each machine is backed by a comprehensive warranty and supported by a dedicated service team, ensuring you have the parts and expertise you need to keep your production running smoothly.
Ready to transform your woodworking productivity? Contact our experts today to discuss your specific needs and find the perfect precision resaw bandsaw for your shop.
