Penutic Pallet Nailing Table, Wood Stringer Pallet Nailer Machine, Wood Pallet Nailing Machine

Revolutionize Your Pallet Production: Build More with Less Effort

Tired of slow, physically demanding pallet assembly? Our universal pneumatic nailing table is engineered to dramatically boost your productivity and eliminate operator strain. By automating the most strenuous tasks, it enables a single operator to build 210-230 high-quality pallets in a standard 8-hour shift. Experience a faster, safer, and more efficient workflow from day one.

A universal pneumatic nailing table, features an adjustable working top, pneumatic clamping of support elements (blocks or stringers), and pneumatic lift of the pallet towards the operator.

Instruction:

• Easy to use One operator can build 240-400 pallets within 8 hours
• Compact design Total footprint 3.3 m² (35.5 ft²)
• Universal Adjustable worktop allows production of:
• Pallets on 2, 3, 4, or 5 stringers
• Efficient Quickly switch to any size pallet
• Pneumatic clamp Easily centers the blocks
• Pneumatic lift Raises pallet to minimize operator lifting
• Overhead roller track Nail guns can move freely during work
• Bottom template Template to build pallet legs
• Adjustable steel clinch plates Galvanized and hardened steel plates for clinching nails
• Unique Diagonal table adjustment reduces work by 50%
• Only 2 Allen keys required to adjust the table

Technical specifications:

Key Benefits & Features:

• Maximized Output & Efficiency:

  • Core Benefit: Significantly increase your production rate. The streamlined pneumatic process allows one person to build 240-400 pallets in 8 hours.

  • Quick Changeover: An adjustable worktop and intuitive setup let you efficiently switch between building pallets on 2, 3, 4, or 5 stringers in minutes, minimizing downtime.

• Ergonomic & Operator-Friendly Design:

  • Pneumatic Lift: The automatic pneumatic lift raises the completed pallet to the perfect height, minimizing operator lifting and reducing fatigue and the risk of injury.

  • Pneumatic Clamp: Effortlessly and precisely secure support elements. The pneumatic clamp easily centers the blocks or stringers for consistent, square pallets every time.

  • Overhead Roller Track: Nail guns are suspended for easy movement, increasing speed and reducing physical effort during nailing.

• Unmatched Versatility & Durability:

  • Universal Pallet Production: The adjustable worktop makes the table truly universal, capable of producing a wide range of pallet sizes and configurations (on 2, 3, 4, or 5 stringers).

  • Precision & Quality: Features like the bottom template ensure perfectly aligned pallet legs, while the adjustable steel clinch plates (made from galvanized and hardened steel) guarantee a secure, professional clinch on every nail.

  • Unique Diagonal Adjustment: Our unique diagonal table adjustment simplifies size changes, cutting adjustment work by an estimated 50%. You only need 2 Allen keys to reconfigure the entire table.

• Compact Footprint:

  • With a total footprint of just 3.3 m² (35.5 ft²), the compact design fits seamlessly into any workshop, saving valuable floor space without compromising on capability.

Detailed Images
